OD6025-24MBIP68
Orion Fans
- Lifecycle status Active
- RoHS RoHS Compliant
- Description24VDC 60X60X25MM IP68
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 199
Can ship immediately
Pricing:
- 1$10.12173
Quote It
Technical Details
- Series:OD6025
- Package:Box
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:25.00mm
- Air Flow:17.0 CFM (0.476m³/min)
- Static Pressure:0.160 in H2O (39.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart
- Noise:25.0dB
- Power (Watts):2.2 W
- RPM:3000 RPM
- Termination:2 Wire Leads
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Operating Temperature:5 ~ 149°F (-15 ~ 65°C)
- Approval Agency:cURus, TUV
- Weight:0.141 lb (63.96 g)
