DC0602512V2B-2T0
Wakefield-Vette
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 12VDC 60X25MM 2WIRES
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 161
Can ship immediately
Pricing:
- 1$13.30965
Quote It
Technical Details
- Series:-
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:25.00mm
- Air Flow:47.8 CFM (1.34m³/min)
- Static Pressure:0.790 in H2O (196.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection
- Noise:63.0dB(A)
- Power (Watts):5.76 W
- RPM:7500 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, cURus, TUV
- Weight:0.126 lb (57.15 g)
