PMD1207PTB3-A.(2).GN
Sunon- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 70X25MM 12VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet PMD1207PTB3-A.(2).GN Datasheet
-
ECAD Model
- Share
In Stock: 119
Can ship immediately
Pricing:
- 1$13.60367
- 30$13.60367
Quote It
Technical Details
- Series:MagLev® PMD
- Package:Bulk
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 70mm L x 70mm H
- Width:25.00mm
- Air Flow:40.0 CFM (1.12m³/min)
- Static Pressure:0.250 in H2O (62.3 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart
- Noise:39.0dB(A)
- Power (Watts):2.9 W
- RPM:4200 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:-
- Approval Agency:-
- Weight:-
