9G1248F1011

Technical Details

• Series:San Ace 120
• Package:Box
• Part Status:Active
• Voltage - Rated:48VDC
• Size / Dimension:Square - 119mm L x 119mm H
• Width:38.00mm
• Air Flow:87.0 CFM (2.44m³/min)
• Static Pressure:0.218 in H2O (54.3 Pa)
• Bearing Type:Ball
• Fan Type:Tubeaxial

• Features:Speed Sensor (Tach)
• Noise:36.0dB(A)
• Power (Watts):4.32 W
• RPM:2280 RPM
• Termination:3 Wire Leads
• Ingress Protection:-
• Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
• Approval Agency:CSA, TUV, UL
• Weight:0.728 lb (330.22 g)
