AFB1524H-A
Delta Electronics / Fans- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 172X150X25.4MM
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$45.80806
Quote It
Technical Details
- Series:AFB
- Package:Bulk
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Rectangular/Rounded - 172mm L x 150mm H
- Width:25.40mm
- Air Flow:202.5 CFM (5.67m³/min)
- Static Pressure:0.467 in H2O (116.3 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection
- Noise:52.0dB(A)
- Power (Watts):12 W
- RPM:3000 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CSA, UL, VDE
- Weight:0.948 lb (430.01 g)
