MJE200G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, 5A, 40
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MJE200G Datasheet
-
ECAD Model
- Share
In Stock: 206,878
Can ship immediately
Pricing:
- 1$0.2
- 10$0.17222
- 100$0.1287
- 500$0.10113
- 1,000$0.07814
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):5 A
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:1.8V @ 1A, 5A
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:45 @ 2A, 1V
- Power - Max:15 W
- Frequency - Transition:65MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-225AA, TO-126-3
- Supplier Device Package:TO-225AA
