2SD1685G

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• Transistor Type:NPN
• Current - Collector (Ic) (Max):5 A
• Voltage - Collector Emitter Breakdown (Max):20 V
• Vce Saturation (Max) @ Ib, Ic:500mV @ 60mA, 3A
• Current - Collector Cutoff (Max):100nA (ICBO)

• DC Current Gain (hFE) (Min) @ Ic, Vce:280 @ 500mA, 2V
• Power - Max:1.5 W
• Frequency - Transition:120MHz
• Operating Temperature:150°C (TJ)
• Mounting Type:Through Hole
• Package / Case:TO-225AA, TO-126-3
• Supplier Device Package:TO-126ML
