TIP120G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, 5A, 60
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet TIP120G Datasheet
-
ECAD Model
- Share
In Stock: 6,370
Can ship immediately
Pricing:
- 1$0.28
- 50$0.2324
- 100$0.19081
- 500$0.15213
- 1,000$0.12295
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN - Darlington
- Current - Collector (Ic) (Max):5 A
- Voltage - Collector Emitter Breakdown (Max):60 V
- Vce Saturation (Max) @ Ib, Ic:4V @ 20mA, 5A
- Current - Collector Cutoff (Max):500µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:1000 @ 3A, 3V
- Power - Max:2 W
- Frequency - Transition:-
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220AB
