BCX54Z
Nexperia- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionBIPOLAR DISCRETES
- CategoryTransistors - Bipolar (BJT) - Single
-
ECAD Model
- Share
In Stock: 1,143
Can ship immediately
Pricing:
- 1$0.37
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):1 A
- Voltage - Collector Emitter Breakdown (Max):45 V
- Vce Saturation (Max) @ Ib, Ic:500mV @ 50mA, 500mA
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:63 @ 150mA, 2V
- Power - Max:500 mW
- Frequency - Transition:180MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-243AA
- Supplier Device Package:SOT-89
