110-13-314-10-001000
Mill-Max
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionCONN IC DIP SOCKET 14POS GOLD
- CategorySockets for ICs, Transistors
- Datasheet 110-13-314-10-001000 Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$12.38768
- 56$12.27232
Quote It
Technical Details
- Series:110
- Package:Tube
- Part Status:Active
- Type:DIP, 0.3" (7.62mm) Row Spacing
- Number of Positions or Pins (Grid):14 (2 x 7), 4 Loaded
- Pitch - Mating:0.100" (2.54mm)
- Contact Finish - Mating:Gold
- Contact Finish Thickness - Mating:30.0µin (0.76µm)
- Contact Material - Mating:Beryllium Copper
- Mounting Type:Through Hole
- Features:Open Frame
- Termination:Solder
- Pitch - Post:0.100" (2.54mm)
- Contact Finish - Post:Gold
- Contact Finish Thickness - Post:30.0µin (0.76µm)
- Contact Material - Post:Brass Alloy
- Housing Material:Polycyclohexylenedimethylene Terephthalate (PCT), Polyester
- Operating Temperature:-55°C ~ 125°C
