CLM-9-30-95-36-AC00-F2-2
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB CLM9 WARM WHITE SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CLM-9-30-95-36-AC00-F2-2 Datasheet
-
ECAD Model
- Share
In Stock: 130
Can ship immediately
Pricing:
- 1$1.8768
- 2,400$1.8768
Quote It
Technical Details
- Series:CLM-9
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):3000K 2-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:520lm (Typ)
- Current - Test:160mA
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):35V
- Lumens/Watt @ Current - Test:93 lm/W
- Current - Max:350mA
- CRI (Color Rendering Index):95
- Viewing Angle:120°
- Features:-
- Size / Dimension:13.50mm L x 13.50mm W
- Height:1.37mm
- Light Emitting Surface (LES):9.00mm Dia
- Lens Type:Flat
