L2-PGC3-S
Califia Lighting (Bivar)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COOL WHT 6500K 1500MA
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet L2-PGC3-S Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$8.2965
- 100$8.2965
Quote It
Technical Details
- Series:L2, XLamp® XP-G
- Package:Tray
- Part Status:Active
- Type:LED Module
- Color:White, Cool
- CCT (K):6500K
- Wavelength:-
- Configuration:Starboard
- Luminous Flux @ Current/Temperature:97lm (Typ)
- Current - Test:350mA
- Temperature - Test:70°C
- Voltage - Forward (Vf) (Typ):2.95V
- Lumens/Watt @ Current - Test:94 lm/W
- Current - Max:1.5A
- CRI (Color Rendering Index):75
- Viewing Angle:45°, 25°
- Features:-
- Size / Dimension:19.90mm L x 19.90mm W
- Height:8.70mm
- Light Emitting Surface (LES):-
- Lens Type:Flat
