BXRE-27E6500-H-23
Bridgelux, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- Description6500 LM WARM WHITE LED ARRAY
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet BXRE-27E6500-H-23 Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$13.30556
- 72$13.30556
Quote It
Technical Details
- Series:V Series™
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Warm
- CCT (K):2700K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:5492lm (Typ)
- Current - Test:1.4A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):34.7V
- Lumens/Watt @ Current - Test:113 lm/W
- Current - Max:2.8A
- CRI (Color Rendering Index):80
- Viewing Angle:120°
- Features:-
- Size / Dimension:28.00mm L x 28.00mm W
- Height:1.70mm
- Light Emitting Surface (LES):22.00mm Dia
- Lens Type:Flat
