CXM-27-50-80-54-AB30-F4-3
Luminus Devices
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionLED COB 5000K COOL WHT SQUARE
- CategoryLED Lighting - COBs, Engines, Modules, Strips
- Datasheet CXM-27-50-80-54-AB30-F4-3 Datasheet
-
ECAD Model
- Share
In Stock: 141
Can ship immediately
Pricing:
- 1$16.65143
- 400$16.1417
Quote It
Technical Details
- Series:CXM-27 Gen3
- Package:Tray
- Part Status:Active
- Type:Chip On Board (COB)
- Color:White, Cool
- CCT (K):5000K 3-Step MacAdam Ellipse
- Wavelength:-
- Configuration:Square
- Luminous Flux @ Current/Temperature:13025lm (Typ)
- Current - Test:1.6A
- Temperature - Test:85°C
- Voltage - Forward (Vf) (Typ):51V
- Lumens/Watt @ Current - Test:160 lm/W
- Current - Max:2.39A
- CRI (Color Rendering Index):80
- Viewing Angle:120°
- Features:-
- Size / Dimension:31.50mm L x 31.50mm W
- Height:1.37mm
- Light Emitting Surface (LES):26.50mm Dia
- Lens Type:Flat
