- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION DPDT 10A 125V
- CategorySnap Action, Limit Switches
- Datasheet 2DM1 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$14.24
- 10$11.04195
- 25$10.46079
- 50$9.87964
- 100$9.0079
- 250$8.42675
- 500$8.13617
- 1,000$7.84559
Quote It
Technical Details
- Series:DM
- Package:Bulk
- Part Status:Active
- Circuit:DPDT
- Switch Function:On-Mom
- Current Rating (Amps):10A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Panel Mount, Snap-In
- Termination Style:Quick Connect - 0.187" (4.7mm)
- Ingress Protection:-
- Features:-
- Operating Force:680gf
- Release Force:170gf
- Pretravel:-
- Differential Travel:0.045" (1.1mm)
- Overtravel:0.400" (10.2mm)
- Operating Temperature:-37°C ~ 82°C
