Z-15GD-5-B7
Omron Automation & Safety Services
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWTCH SPDT 15A SHORT SPRNG PLNGR
- CategorySnap Action, Limit Switches
- Datasheet Z-15GD-5-B7 Datasheet
-
ECAD Model
- Share
In Stock: 131
Can ship immediately
Pricing:
- 1$17.08
- 10$13.24298
- 25$12.54626
- 50$11.84913
- 100$10.80354
- 250$10.10658
- 500$9.75808
- 1,000$9.40957
Quote It
Technical Details
- Series:Z
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):15A (AC), 6A (DC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:30 V
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:IP40
- Features:-
- Operating Force:250 ~ 350gf
- Release Force:114gf
- Pretravel:0.015" (0.4mm)
- Differential Travel:0.002" (0.05mm)
- Overtravel:0.062" (1.6mm)
- Operating Temperature:-25°C ~ 80°C
