- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSWITCH SNAP ACTION SPDT 15A 125V
- CategorySnap Action, Limit Switches
- Datasheet BZ-R-A2 Datasheet
-
ECAD Model
- Share
In Stock: 106
Can ship immediately
Pricing:
- 1$17.31
- 10$12.98596
- 25$11.90348
- 50$11.18205
- 100$10.46063
- 250$10.09992
- 500$9.73921
Quote It
Technical Details
- Series:BZ
- Package:Bulk
- Part Status:Active
- Circuit:SPDT
- Switch Function:On-Mom
- Current Rating (Amps):15A (AC)
- Voltage Rating - AC:125 V
- Voltage Rating - DC:-
- Actuator Type:Round (Pin Plunger)
- Mounting Type:Chassis Mount
- Termination Style:Screw Terminal
- Ingress Protection:-
- Features:-
- Operating Force:198 ~ 255gf
- Release Force:113gf
- Pretravel:0.012" (0.3mm)
- Differential Travel:0.0003" (0.008mm)
- Overtravel:0.005" (0.13mm)
- Operating Temperature:-55°C ~ 85°C
