NDF04N60ZH
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 4.8A TO220FP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NDF04N60ZH Datasheet
-
ECAD Model
- Share
In Stock: 119,028
Can ship immediately
Pricing:
- 1$0.28
- 1,500$0.28
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:4.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:2Ohm @ 2A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 50µA
- Gate Charge (Qg) (Max) @ Vgs:29 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:640 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):30W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220FP
- Package / Case:TO-220-3 Full Pack
