NTTS2P02R2G

Technical Details

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:2.4A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:90mOhm @ 2.4A, 4.5V
• Vgs(th) (Max) @ Id:1.4V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:18 nC @ 4.5 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:550 pF @ 16 V
• FET Feature:-
• Power Dissipation (Max):780mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:Micro8™
• Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
