SFT1445-TL-H
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 100V 17A TP-FA
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet SFT1445-TL-H Datasheet
-
ECAD Model
- Share
In Stock: 1,437
Can ship immediately
Pricing:
- 1$1.15
- 700$0.68793
- 1,400$0.5431
- 2,100$0.50689
- 4,900$0.48155
- 17,500$0.46344
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):100 V
- Current - Continuous Drain (Id) @ 25°C:17A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4V, 10V
- Rds On (Max) @ Id, Vgs:111mOhm @ 8.5A, 10V
- Vgs(th) (Max) @ Id:2.6V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:19 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1030 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):1W (Ta), 35W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TP-FA
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
