FDD390N15A
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 150V 26A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet FDD390N15A Datasheet
-
ECAD Model
- Share
In Stock: 395,930,194
Can ship immediately
Pricing:
- 1$1.16
- 2,500$0.54023
- 5,000$0.51471
- 12,500$0.49648
Quote It
Technical Details
- Series:PowerTrench®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):150 V
- Current - Continuous Drain (Id) @ 25°C:26A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:40mOhm @ 26A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:18.6 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1285 pF @ 75 V
- FET Feature:-
- Power Dissipation (Max):63W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
