PMG85XP,115

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:2A (Tj)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:115mOhm @ 2A, 4.5V
• Vgs(th) (Max) @ Id:1.15V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:7.2 nC @ 4.5 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:560 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):375mW (Ta), 2.4W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:6-TSSOP
• Package / Case:6-TSSOP, SC-88, SOT-363
