PMCM440VNEZ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 12V 3.9A 4WLCSP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet PMCM440VNEZ Datasheet
-
ECAD Model
- Share
In Stock: 90,123
Can ship immediately
Pricing:
- 1$0.06
- 9,000$0.06
- 18,000$0.05533
- 27,000$0.05221
- 63,000$0.04754
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):12 V
- Current - Continuous Drain (Id) @ 25°C:3.9A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):4.5V
- Rds On (Max) @ Id, Vgs:67mOhm @ 3A, 4.5V
- Vgs(th) (Max) @ Id:900mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:8.2 nC @ 4.5 V
- Vgs (Max):±8V
- Input Capacitance (Ciss) (Max) @ Vds:360 pF @ 6 V
- FET Feature:-
- Power Dissipation (Max):400mW (Ta), 12.5W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:4-WLCSP (0.78x0.78)
- Package / Case:4-XFBGA, WLCSP
