PMN48XPAX
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET P-CH 20V 4.1A 6TSOP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet PMN48XPAX Datasheet
-
ECAD Model
- Share
In Stock: 24,195
Can ship immediately
Pricing:
- 1$0.06
- 3,000$0.06
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:4.1A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
- Rds On (Max) @ Id, Vgs:55mOhm @ 2.4A, 4.5V
- Vgs(th) (Max) @ Id:1.25V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:13 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:1 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):530mW (Ta), 6.25W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:6-TSOP
- Package / Case:SC-74, SOT-457
