NVJS4405NT1G

Technical Details

• Series:-
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):25 V
• Current - Continuous Drain (Id) @ 25°C:1A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.7V, 4.5V
• Rds On (Max) @ Id, Vgs:350mOhm @ 600mA, 4.5V
• Vgs(th) (Max) @ Id:1.5V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:1.5 nC @ 4.5 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:60 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):630mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SC-88/SC70-6/SOT-363
• Package / Case:6-TSSOP, SC-88, SOT-363
