PMPB10XNEZ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPMPB10XNE - 20 V, SINGLE N-CHANN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet PMPB10XNEZ Datasheet
-
ECAD Model
- Share
In Stock: 136
Can ship immediately
Pricing:
- 1$0.1
- 3,000$0.04611
- 6,000$0.04352
- 15,000$0.04092
- 30,000$0.03911
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:9A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:14mOhm @ 9A, 4.5V
- Vgs(th) (Max) @ Id:900mV @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:34 nC @ 4.5 V
- Vgs (Max):±12V
- Input Capacitance (Ciss) (Max) @ Vds:2.175 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):1.7W (Ta), 12.5W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DFN2020MD-6
- Package / Case:6-UDFN Exposed Pad
