BUK7Y20-30B,115
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 39.5A LFPAK56
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet BUK7Y20-30B,115 Datasheet
-
ECAD Model
- Share
In Stock: 10,690
Can ship immediately
Pricing:
- 1$0.16
- 1,500$0.16
Quote It
Technical Details
- Series:Automotive, AEC-Q101, TrenchMOS™
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:39.5A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:20mOhm @ 20A, 10V
- Vgs(th) (Max) @ Id:4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:11.2 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:688 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):59W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:LFPAK56, Power-SO8
- Package / Case:SC-100, SOT-669
