NTD4909NT4G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 8.8A/41A DPAK
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTD4909NT4G Datasheet
-
ECAD Model
- Share
In Stock: 12,506
Can ship immediately
Pricing:
- 1$0.26
- 2,500$0.24961
- 5,000$0.23351
- 12,500$0.2174
- 25,000$0.20613
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:8.8A (Ta), 41A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:8mOhm @ 30A, 10V
- Vgs(th) (Max) @ Id:2.2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:17.5 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1.314 pF @ 15 V
- FET Feature:-
- Power Dissipation (Max):1.37W (Ta), 29.4W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:DPAK
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
