NTMFS4837NHT1G
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 30V 10.2A/75A 5DFN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NTMFS4837NHT1G Datasheet
-
ECAD Model
- Share
In Stock: 19,617
Can ship immediately
Pricing:
- 1$0.38
- 1,500$0.38
- 3,000$0.34437
- 7,500$0.32062
- 10,500$0.30875
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):30 V
- Current - Continuous Drain (Id) @ 25°C:10.2A (Ta), 75A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 11.5V
- Rds On (Max) @ Id, Vgs:5mOhm @ 30A, 10V
- Vgs(th) (Max) @ Id:2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:23.8 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:3.016 pF @ 12 V
- FET Feature:-
- Power Dissipation (Max):880mW (Ta), 48W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:5-DFN (5x6) (8-SOFL)
- Package / Case:8-PowerTDFN, 5 Leads
