CSD18502KCS
Texas Instruments
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 40V 100A TO220-3
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 570
Can ship immediately
Pricing:
- 1$2.53
- 10$2.28488
- 50$2.04446
- 100$1.84408
- 500$1.44313
- 1,000$1.2026
- 2,500$1.1625
Quote It
Technical Details
- Series:NexFET™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):40 V
- Current - Continuous Drain (Id) @ 25°C:100A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:2.9mOhm @ 100A, 10V
- Vgs(th) (Max) @ Id:2.1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:62 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:4680 pF @ 20 V
- FET Feature:-
- Power Dissipation (Max):259W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220-3
- Package / Case:TO-220-3
