IRFP440PBF
Vishay / Siliconix
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 500V 8.8A TO247-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRFP440PBF Datasheet
-
ECAD Model
- Share
In Stock: 217
Can ship immediately
Pricing:
- 1$3.05
- 25$2.46153
- 100$2.21538
- 500$1.72303
- 1,000$1.42766
- 2,500$1.3292
- 5,000$1.27996
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):500 V
- Current - Continuous Drain (Id) @ 25°C:8.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:850mOhm @ 5.3A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:63 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1300 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):150W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-247-3
- Package / Case:TO-247-3
