STP6NK90Z
STMicroelectronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 900V 5.8A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet STP6NK90Z Datasheet
-
ECAD Model
- Share
In Stock: 447
Can ship immediately
Pricing:
- 1$3.19
- 50$2.5712
- 100$2.3141
- 500$1.79988
- 1,000$1.49133
- 2,500$1.38848
- 5,000$1.33705
Quote It
Technical Details
- Series:SuperMESH™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):900 V
- Current - Continuous Drain (Id) @ 25°C:5.8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:2Ohm @ 2.9A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 100µA
- Gate Charge (Qg) (Max) @ Vgs:60.5 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:1350 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):140W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220AB
- Package / Case:TO-220-3
