IXTT240N15X4HV
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 150V 240A TO268HV
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 80,812
Can ship immediately
Pricing:
- 1$19.57
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):150 V
- Current - Continuous Drain (Id) @ 25°C:240A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:4.4mOhm @ 120A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:195 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:8900 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):940W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-268HV
- Package / Case:TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
