FCPF4300N80Z

Technical Details

• Series:SuperFET® II
• Package:Bulk
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):800 V
• Current - Continuous Drain (Id) @ 25°C:1.6A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:4.3Ohm @ 800mA, 10V
• Vgs(th) (Max) @ Id:4.5V @ 160µA

• Gate Charge (Qg) (Max) @ Vgs:8.8 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:355 pF @ 100 V
• FET Feature:-
• Power Dissipation (Max):19.2W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-220F
• Package / Case:TO-220-3 Full Pack
