IRF5802TRPBF
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 150V 900MA MICRO6
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IRF5802TRPBF Datasheet
-
ECAD Model
- Share
In Stock: 526
Can ship immediately
Pricing:
- 1$0.6
- 3,000$0.2474
- 6,000$0.23304
- 15,000$0.21868
- 30,000$0.20863
Quote It
Technical Details
- Series:HEXFET®
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):150 V
- Current - Continuous Drain (Id) @ 25°C:900mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:1.2Ohm @ 540mA, 10V
- Vgs(th) (Max) @ Id:5.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:6.8 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:88 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):2W (Ta)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:Micro6™(TSOP-6)
- Package / Case:SOT-23-6 Thin, TSOT-23-6
