IRLS3036TRL7PP

Technical Details

• Series:HEXFET®
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:240A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:1.9mOhm @ 180A, 10V
• Vgs(th) (Max) @ Id:2.5V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:160 nC @ 4.5 V
• Vgs (Max):±16V
• Input Capacitance (Ciss) (Max) @ Vds:11270 pF @ 50 V
• FET Feature:-
• Power Dissipation (Max):380W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:D2PAK (7-Lead)
• Package / Case:TO-263-7, D²Pak (6 Leads + Tab), TO-263CB
