AOB290L

Technical Details

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Not For New Designs
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):100 V
• Current - Continuous Drain (Id) @ 25°C:18A (Ta), 140A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:3.2mOhm @ 20A, 10V
• Vgs(th) (Max) @ Id:4.1V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:126 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:9550 pF @ 50 V
• FET Feature:-
• Power Dissipation (Max):2.1W (Ta), 500W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:TO-263 (D²Pak)
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
