IPD046N08N5ATMA1
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 80V 90A TO252-3
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IPD046N08N5ATMA1 Datasheet
-
ECAD Model
- Share
In Stock: 169
Can ship immediately
Pricing:
- 1$2.25
- 2,500$1.02805
Quote It
Technical Details
- Series:OptiMOS™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):80 V
- Current - Continuous Drain (Id) @ 25°C:90A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):6V, 10V
- Rds On (Max) @ Id, Vgs:4.6mOhm @ 45A, 10V
- Vgs(th) (Max) @ Id:3.8V @ 65µA
- Gate Charge (Qg) (Max) @ Vgs:53 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:3800 pF @ 40 V
- FET Feature:-
- Power Dissipation (Max):125W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:PG-TO252-3
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
