IAUA180N04S5N012AUMA1

Technical Details

• Series:OptiMOS™-5
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):40 V
• Current - Continuous Drain (Id) @ 25°C:180A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):7V, 10V
• Rds On (Max) @ Id, Vgs:1.2mOhm @ 90A, 10V
• Vgs(th) (Max) @ Id:3.4V @ 70µA

• Gate Charge (Qg) (Max) @ Vgs:100 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:6158 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):125W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-HSOF-5-1
• Package / Case:5-PowerSFN
