AOI600A60
Alpha and Omega Semiconductor, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 8A TO251A
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 180
Can ship immediately
Pricing:
- 1$1.32
Quote It
Technical Details
- Series:aMOS5™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:8A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:600mOhm @ 2.1A, 10V
- Vgs(th) (Max) @ Id:3.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:11.5 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:608 pF @ 100 V
- FET Feature:-
- Power Dissipation (Max):96W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-251A
- Package / Case:TO-251-3 Stub Leads, IPak
