MTP20N15EG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 150V 20A TO220AB
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet MTP20N15EG Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$1.41
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):150 V
- Current - Continuous Drain (Id) @ 25°C:20A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:130mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id:4V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:55.9 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1.627 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):112W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:TO-220AB
- Package / Case:TO-220-3
