XP202A0003PR-G

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:5A (Tj)
• Drive Voltage (Max Rds On, Min Rds On):4V, 10V
• Rds On (Max) @ Id, Vgs:59mOhm @ 3A, 10V
• Vgs(th) (Max) @ Id:2.6V @ 1mA

• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:450 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):1.5W
• Operating Temperature:150°C
• Mounting Type:Surface Mount
• Supplier Device Package:SOT-89
• Package / Case:TO-243AA
