NVTFS5C658NLTAG
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 60V 109A 8WDFN
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet NVTFS5C658NLTAG Datasheet
-
ECAD Model
- Share
In Stock: 1,652
Can ship immediately
Pricing:
- 1$0.95
- 1,500$0.5581
- 3,000$0.5209
- 7,500$0.49485
- 10,500$0.47625
Quote It
Technical Details
- Series:Automotive, AEC-Q101
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):60 V
- Current - Continuous Drain (Id) @ 25°C:109A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
- Rds On (Max) @ Id, Vgs:5mOhm @ 50A, 10V
- Vgs(th) (Max) @ Id:2.2V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:12 nC @ 4.5 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:1935 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):114W (Tc)
- Operating Temperature:-55°C ~ 175°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-WDFN (3.3x3.3)
- Package / Case:8-PowerWDFN
