NP180N04TUK-E1-AY

Technical Details

• Series:-
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):40 V
• Current - Continuous Drain (Id) @ 25°C:180A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:1.05mOhm @ 90A, 10V
• Vgs(th) (Max) @ Id:4V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:297 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:15750 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):1.8W (Ta), 348W (Tc)
• Operating Temperature:175°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:TO-263-7
• Package / Case:TO-263-7, D²Pak (6 Leads + Tab)
