IXFT140N20X3HV
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 200V 140A TO268HV
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXFT140N20X3HV Datasheet
-
ECAD Model
- Share
In Stock: 1,052
Can ship immediately
Pricing:
- 1$11.16233
- 30$9.15311
- 120$8.26012
- 510$6.92064
- 1,020$6.2509
Quote It
Technical Details
- Series:HiPerFET™
- Package:Tube
- Part Status:Active
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):200 V
- Current - Continuous Drain (Id) @ 25°C:140A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:9.6mOhm @ 70A, 10V
- Vgs(th) (Max) @ Id:4.5V @ 4mA
- Gate Charge (Qg) (Max) @ Vgs:127 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:7660 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):520W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:TO-268HV
- Package / Case:TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
