- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionP-CH MOSFET 16V 7A DFN2020-6L-C-
- CategoryTransistors - FETs, MOSFETs - Single
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$0.47
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- FET Type:P-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):20 V
- Current - Continuous Drain (Id) @ 25°C:7A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
- Rds On (Max) @ Id, Vgs:36.5mOhm @ 7A, 4.5V
- Vgs(th) (Max) @ Id:1V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:40.1 nC @ 4.5 V
- Vgs (Max):±10V
- Input Capacitance (Ciss) (Max) @ Vds:852 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):2.2W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:6-DFN (2x2)
- Package / Case:6-UDFN Exposed Pad
