IRLZ14L

Technical Details

• Series:-
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:10A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4V, 5V
• Rds On (Max) @ Id, Vgs:200mOhm @ 6A, 5V
• Vgs(th) (Max) @ Id:2V @ 250µA

• Gate Charge (Qg) (Max) @ Vgs:8.4 nC @ 5 V
• Vgs (Max):±10V
• Input Capacitance (Ciss) (Max) @ Vds:400 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):3.7W (Ta), 43W (Tc)
• Operating Temperature:-55°C ~ 175°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-262-3
• Package / Case:TO-262-3 Long Leads, I²Pak, TO-262AA
