TPCA8010-H(TE12L,Q
Toshiba Electronic Devices and Storage Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 200V 5.5A 8SOP
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet TPCA8010-H(TE12L,Q Datasheet
-
ECAD Model
- Share
In Stock: 125
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:π-MOSV
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):200 V
- Current - Continuous Drain (Id) @ 25°C:5.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:450mOhm @ 2.7A, 10V
- Vgs(th) (Max) @ Id:4V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs:10 nC @ 10 V
- Vgs (Max):±20V
- Input Capacitance (Ciss) (Max) @ Vds:600 pF @ 10 V
- FET Feature:-
- Power Dissipation (Max):1.6W (Ta), 45W (Tc)
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Supplier Device Package:8-SOP Advance (5x5)
- Package / Case:8-PowerVDFN
