IXFV30N50PS

Technical Details

• Series:HiPerFET™, PolarHT™
• Package:Tube
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):500 V
• Current - Continuous Drain (Id) @ 25°C:30A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:200mOhm @ 15A, 10V
• Vgs(th) (Max) @ Id:5V @ 4mA

• Gate Charge (Qg) (Max) @ Vgs:70 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:4150 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):460W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PLUS-220SMD
• Package / Case:PLUS-220SMD
