IXFC22N60P
Wickmann / Littelfuse
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionMOSFET N-CH 600V 12A ISOPLUS220
- CategoryTransistors - FETs, MOSFETs - Single
- Datasheet IXFC22N60P Datasheet
-
ECAD Model
- Share
In Stock: 135
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:HiPerFET™, PolarHT™
- Package:Tube
- Part Status:Obsolete
- FET Type:N-Channel
- Technology:MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):600 V
- Current - Continuous Drain (Id) @ 25°C:12A (Tc)
- Drive Voltage (Max Rds On, Min Rds On):10V
- Rds On (Max) @ Id, Vgs:360mOhm @ 11A, 10V
- Vgs(th) (Max) @ Id:5V @ 4mA
- Gate Charge (Qg) (Max) @ Vgs:58 nC @ 10 V
- Vgs (Max):±30V
- Input Capacitance (Ciss) (Max) @ Vds:4000 pF @ 25 V
- FET Feature:-
- Power Dissipation (Max):130W (Tc)
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Supplier Device Package:ISOPLUS220™
- Package / Case:ISOPLUS220™
